| Tank type/filter | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
◆◆ tank type A: purified water tank: this product is used for electrodialysis, reverse osmosis, single stage double stage reverse osmosis water purification system,
B：injection tank： This company production of W (L) zh type injection water tank, reasonable design, advanced technology, automatic control, in line with the national GMP certification requirements, choose 304 or 316L stainless steel made. The use of horizontal or vertical double-layer structure, and the interlayer wall around the steam pipe welding of spiral or U type boiler, and filling insulation materials. The Ra0. 5um polished to smooth, no dead angle, the external use of mirror plate or matte board insulation. Can meet the requirements of GMP of pure steam sterilization, configuration 0.22um respirators, 360 degree rotating washing tank, liquid level device and is provided with a water inlet, reflux mouth, pure steam sterilization, washing tank interface, respirator interface, a water outlet and a drain outlet and a sampling port.
◆◆ Fermentation pot series: fermentation tank, the seed can be made of carbon steel, stainless steel two, mainly for the production of biochemical fermentation. Such as the production of monosodium glutamate, citric acid, enzyme preparation, glycerol, pharmaceutical, food and other industries, the product manufacturing acceptance, according to GB150-98 "steel pressure vessel" requirements. ◆◆ filter Main features: precision casting production, high manufacturing precision, less weld, pressure stability, and easy to operate. , a typical sealing structure design. With special design of hot melt filter bag (steel ring or plastic ring), can ensure filter and filtration processes almost 100% without leakage. filter installation and operation is simple and convenient, covers an area of small, wide range of uses, can be used for coarse filtration, filtration or fine filtration. , combined with the most reasonable and compact pipe connection and full grinding and polishing of the filter basket, so that the filter itself and the connection inside the pipe without impurity deposition, filtration efficiency, and the operation of the space is also minimal. lock locking device can all use stainless steel eyebolt assembly to replace ordinary carbon steel galvanized parts, can prevent the filter is put to use for a number of years after the bolt rusting phenomenon. < p >, to achieve the same filtering effect, the plate and frame filter, filter type filter, raw water pre filter and fine filter, such as equipment with low investment costs, the use of long life and filter low cost.in the same reasonable structure, low operating costs, filter effects and handling of the case, with a high cost. |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
EDI water storage device. Tank body is divided into two kinds of vertical and horizontal, according to different process requirements for: 316L, 304 two, inside and outside the tank were overall polishing processing Ra0.45 DEG tank can meet the requirements of GMP of pure steam sterilization, configuration 0.22um respirators, 360. Rotary washing tank, the liquid level device, is provided with a water inlet, reflux mouth, pure steam sterilization, washing tank interface, respirator interface, a water outlet and a drain outlet and a sampling port. Can also be based on user requirements of the process of different 1:3 and other devices. The volume of production of 0.5-50m3 equipment can be. The inner surface can be mechanically polished to Ra< 0.6um, polishing to Ra< 0.5um.
